DOWSIL™ 3-1953 CONFORMAL COATING 94V0 3.6P,18.1KG-PAIL
One Part/Non-solvent/Low temp. curing
Contact us
Description
DOWSIL™ 3-1953 Application description： suitable for use as a protective coating for rigid and flexible circuit boards.
Additional information
| Brand | DOWSIL |
|---|---|
| Manufacturer SKU | 4001900 |
| Application | Conformal Coating |
| Market application | General Industry, Solar Energy |
| Mix Ratio by Weight | One Part |
| Material | SILICONE |
| Color/Appearance | Translucent |
| Viscosity (mPa.s) | 350 |
| Tack-Free Time | 8 mins @ 25℃ |
| Cure Condition | 10 mins @ 60℃ |
| Certification | Amend.1, Amend.7, IPC-CC-830A, MIL-I-46058C, UL 746E, UL 94 V-0 |
| Specific Gravity | 0.98 |
| Hardness (Shore) | 34 (A) |
| Tensile Strength (psi) | 80 |
| Dielectric Strength (KV/mm ) | 17 |
| Volume Resistivity (ohm*cm) | 5.50E+15 |
More Information
If you want to know more about the use of the product or related certification, such as UL,RoHS,REACH,European Union Regulations, Please make use of the inquiry form or telephone.
